Technical Specifications:

• Picture/Display

  -Panel Size: 23.8"/60.5 cm

  -Aspect ratio: 16:9

  -LCD panel type: Fast IPS

  -Backlight type: W-LED system

  -Pixel pitch: 0.2745 x 0.2745mm

  -Brightness: 300  cd/m²

  -Display colors: 16.7 M

  -Color gamut (typical): Adobe RGB 86%; DCI-P3:87%, sRGB: 109%, NTSC 99% *

  -Contrast ratio (typical): 1000:1

  -SmartContrast: Mega Infinity DCR

  -Response time (typical): 1 ms (Gray to Gray)*

  -Viewing angle:

  • 178º (H) / 178º (V)

  • @ C/R > 10

  -Picture enhancement: SmartImage game

  -Maximum resolution: 1920x1080 @ 260Hz (Overclock*, HDMI/DP)

  -Effective viewing area: 527.04(H)x296.46(V)mm

  -Scanning Frequency: 30-290kHz(H)/ 48-260Hz(V) (Overclock)*

  -sRGB: Yes

  -Flicker-free: Yes

  -Pixel Density: 93 PPI

  -LowBlue Mode: Yes

  -Display Screen Coating: Anti-Glare, 3H, Haze 25%

  -Low Input Lag: Yes

  -Adaptive sync (VRR): Yes

  -G-SYNC: Yes

  -HDR: HDR 10 supported

  -Smart MBR: 0.3ms*

  -Smart MBR Sync: Yes

  -Smart Crosshair: Yes

  -Shadow Boost: Yes

  -SoftBlue technology: Yes*

• Connectivity

  -Signal Input: HDMI 2.0 x 1, DisplayPort 1.4 x 1

  -Sync Input: Separate Sync

  -Audio (In/Out): Headphone out

  -HDCP: HDCP 1.4 (HDMI / DP), HDCP 2.2 (HDMI / DP)

• Convenience

  -Plug & Play Compatibility

  • DDC/CI

  • Mac OS

  • sRGB

  • Windows 11 / 10

  -User convenience

  • Power On/Off

  • Menu/OK

  • Input/Up

  • Game Settings/Down

  • SmartImage game/Back

  -OSD Languages

  • Brazil Portuguese

  • Czech

  • Dutch

  • English

  • Finnish

  • French

  • German

  • Greek

  • Hungarian

  • Italian

  • Japanese

  • Korean

  • Polish

  • Portuguese

  • Russian

  • Spanish

  • Simplified Chinese

  • Swedish

  • Turkish

  • Traditional Chinese

  • Ukrainian

  -Other convenience

  • Kensington lock

  • VESA mount (100x100mm)

  • LowBlue Mode

  -Control software: Evnia Precision Center

• Stand

  -Tilt: -5/20  degree

• Power

  -Power supply

  • Internal

  • 100-240VAC, 50-60Hz

  -Off mode: 0.3 W (typ.)

  -On mode: 18.3 W (typ.)

  -Standby mode: 0.5 W (typ.)

  -Power LED indicator

  • Operation - White

  • Standby mode- White (blinking)

• Dimensions

  -Packaging in mm (WxHxD): 690 x 420 x 124  mm

  -Product without stand (mm): 544 x 321 x 50  mm

  -Product with stand(max height): 544 x 433 x 216  mm

• Weight

  -Product with packaging (kg): 5.27  kg

  -Product with stand (kg): 3.07  kg

  -Product without stand (kg): 2.52  kg

• Operating conditions

  -Altitude: Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

  -Temperature range (operation): 0°C to 40  °C

  -MTBF: 50,000 (Excluded backlight)  hour(s)

  -Relative humidity: 20%-80  %

  -Temperature range (storage): -20°C to 60  °C

• Sustainability

  -Environmental and energy: RoHS

  -Recyclable packaging material: 100  %

  -Post consumer recycled plastics: 85%*

• Compliance and standards

  -Regulatory Approvals

  • CB

  • CE Mark

  • MEPS

  • PSB

  • CEL

  • CCC

  • CECP

  • BSMI

  • UKCA

  • EMF

  • FCC

  • ICES-003

• Cabinet

  -Color: Charcoal

  -Finish: Textured
